Layer information

Layer Name	IMAGE_Ortho2005AerialsExpressNAT
Subject Category	Imagery
Title	2005 Aerials Express natural color orthoimagery
Feature Count	1
Feature Type	Polygon
Published Date	None planned
Spatial reference	NAD 1983 HARN StatePlane Washington North FIPS 4601 Feet
Open Data Availability	Not Available
Place Keywords	King County; WA, Washington State, United States, Pacific NW
Theme Keywords	Orthophotography, Orthoimagery, Imagerybasemapsearthcover
Supplemental Information	None

Attribute information

OBJECTID From Esri	Description Internal feature number. Domain Sequential unique whole numbers that are automatically generated.
Shape From Esri	Description Feature geometry. Domain Coordinates defining the features.
Shape_Length From Esri	Description Length of feature in internal units. Domain Positive real numbers that are automatically generated.
Shape_Area From Esri	Description Area of feature in internal units squared. Domain Positive real numbers that are automatically generated.
MosaicID No Source Noted	Description Not Found Domain Not Found

Purpose

Color orthophoto imagery for King Co and portions of adjoining counties

Abstract

Year 2005 (July) Aerials Express Natural Color orthoimagery acquired by King County for internal business and agency use only.

Pixel resolution is 1.0 foot and coverage is western, urbanized, portions of King County, southwestern Snohomish County and a buffer into Pierce County..

Contact information

Maintained by	KCGIS Center
Primary	KCGIS Center giscenter@kingcounty.gov

Constraints

Access	Access to the data is limited to King County government agencies. The data is not to be redistributed in digital form to any other users. Limited use within a defined scope-of-work may be allowed for non-KC entities working for King County.
Use	King County digital data may not be reproduced or redistributed in any form or by any means without the express written authorization of the King County Department of Natural Resources and Parks/KCGIS-Center.

Change history

9/1/2006	The data had been tiled to King County's 7500 tiling scheme by Aerial Express. Tiles were renamed to King County's standard naming convention and stored in the Spatial Data Warehouse. The tiles were inventoried, selected edge tiles containing very little valid data were removed. The remaining tiles were submitted to an ArcInfo AML-driven grid routine to create temporary tile sets clipped to each of the townships within the extent of the data. These tile sets were then mosaiced and compressed (7x) using MrSid software.
8/1/2006	Data acquired from Aerials Express in August 2006 via portable harddrive. Original delivery did not contain all the required tiles. Aerials Express resubmitted the project area in its entirety in the second harddrive delivery.
