Contour Cluster Index Table
Learn how to get an ArcGIS Online account 🗺
Use this Data
|
Links
How to use in ArcGIS Pro |
|
| Sharing Status | Not Public |
Summary
Used to join to PLSS_TWN_AREA on item TWNRNG.
When joined can be symbolized or queried to determine which contour cluster is available for coverage in a given area.
Description
A relate table that provides infomration about which contour cluster is available for that area.
Contour clusters where created to bundle township 5-contour layers into groups of of 9 township tiles.
There are 9 clusters corresponding to 9 group layer files.
Loading a contour cluster via its respective layer file makes available all 9 tiles rather than having to load 9 separate township tiles.
Layer information
| Layer Name | ctrclusters |
| Subject Category | Survey |
| Title | Contour Cluster Index Table |
| Feature Count | 222 |
| Feature Type | Polygon |
| Next Update | As needed |
| Spatial reference | None |
| Control ID | 2202 |
| Place Keywords | Pacific NW, Washington State, Snohomish County, WA |
| Theme Keywords | PLSS, None, Survey, Reference Grids, Contours |
| Supplemental Information |
None |
Attribute information
|
OBJECTID
From ESRI |
Description
Internal feature number. DomainSequential unique whole numbers that are automatically generated. |
|
TWNRNG
From King County |
Description
Cocantenated township and range identifier DomainPLSS township number appended to range number, expressed as integer, e.g., 1907 |
|
CTRCLUSTER
From King County |
Description
Name of contour cluster, corresponding to name of Plibrary layer file. DomainText string |
Contact information
| Maintained by | KCGIS Center |
| Primary |
KCGIS Center
giscenter@kingcounty.gov |
Terms of Use
| License | Terms of use and copyright |
Use this Data
|
Links
How to use in ArcGIS Pro |
|
| Sharing Status | Not Public |
Summary
Used to join to PLSS_TWN_AREA on item TWNRNG.
When joined can be symbolized or queried to determine which contour cluster is available for coverage in a given area.
Description
A relate table that provides infomration about which contour cluster is available for that area.
Contour clusters where created to bundle township 5-contour layers into groups of of 9 township tiles.
There are 9 clusters corresponding to 9 group layer files.
Loading a contour cluster via its respective layer file makes available all 9 tiles rather than having to load 9 separate township tiles.
Contact information
| Maintained by | KCGIS Center |
| Primary |
KCGIS Center
giscenter@kingcounty.gov |
Terms of use and copyright
| License | Terms of use and copyright |
Change history
| 1/1/2004 |
PLSS_QTR dissolved on TWNRNG item |
| Update 2 |
dissolved to produce PLSS_TWN |
| Update 3 |
Updated PLSS dissolved by Township to produce PLSS_TWN |
